Valencia Lift
Advantages
Custom-designed to suit your home
We tailor each lift to suit each shaftway. Special solutions are available for existing buildings where shallow pits and restricted headroom are required.
Cost and energy efficient
The Valencia lift is an energy-efficient option, reducing consumption by up to 50% compared to similar conventional hydraulic lifts.
Enclosure options
Custom enclosures are available, which can be used to replace the traditional shaftway.
Customisable to your needs
Choose from a wide range of models and finishes and create a lift that meets your specific needs and complements its surrounds.
Manufacturing you can trust
Engineered by Raloe, one of Europe’s leaders in quality lifts for home and commercial use.
Residential & commercial applications
The Valencia lift can be installed in either private homes or commercial buildings, such as offices, hotels, airports, shopping centres, and more. If you’re interested in the Valencia for a commercial project, click here.
Safety
Extensively tested
The Valencia lift has been extensively safety tested, so you know that all visitors to your home can enjoy its benefits with complete reliabilty and comfort. It meets all required Australian lift standards and safety requirements.
Automatic emergency system
An automatic emergency system with a pressure release valve is always active during downward travel even in the event of motor failure.
Overload pressure switch
A pneumatic pressure switch with an acoustic buzzer prohibits the lift from moving if it’s ever overloaded..
Safety rupture valve
A rupture valve is included for additional safety.
Standard Dimensions
Standard headroom: 3500mm
Standard pit: 1200mm
Is the Valencia lift not quite right for your needs?
View our full range of home lifts here or contact us today.
Technical Specs
- Up to 25m travel
- Speed 0.63 – 1 m/s
- Rated load: 1500kg
- Traffic: 30 to 45 starts/hr
- Roped Hydraulic
- Internal and external applications
For more information, download brochure
DOWNLOAD
- Up to 12m travel
- Speed: 0.15 m/s
- Rated Load: 400kg
- Hydraulic drive
- Internal and external applications
- Up to 25m travel
- Speed: 0.63 m/s to 1.6 m/s using 3-phase power
- Rated load: up to 3000kg dependent on size
- MRL Traction
- Internal and external applications
- Up to 12m travel
- Speed 0.3 m/s
- Rated load: 500kg
- Roped Hydraulic
- Internal and external applications
- Up to 12m travel
- Speed 0.2 m/s
- Rated load: 455kg
- Roped hydraulic
- Internal and external applications
